| Digital Friabilator |
| (Model : FTA-20) |
|
|
|
| |
| Campbell Electronics new Tablet Friability Testers are designed to replace the bulky, troublesome and expensive models in the market. Friabilator has now become an accepted standard throughout the pharmaceutical industry for determining the resistance of tablets to the abrasion and shock experienced in manufacturing, packing and shipping operations. Campbell Electronics Friabilators FTA-20 is designed in accordance with the specifications as laid down in USP and other pharmacopoeia. In FTA-20 can be used to run the test either one or two friability drums / one or two abrasion drums. This model can also be used with one friability drum and one abrasion drum for making comparisons between the two parameters under identical test conditions. The Friabilator FTA-20 having variable speed between 20 and 75 rpm and printer interface facility. |
|
|
|
|
| |
| Salient Features: |
| |
 |
Complies to USP and other pharmacopoeias |
|
Compact, Simple & Easy to Operate |
|
Cost Effective. |
|
Supports friability drum with single scoop (standard), friability drum with double scoop and abrasion drum. |
|
Auto discharge of tablets after friability test with single scoop friability drum. |
|
Dual mode of operation timer mode or revolution count mode. |
|
20X4 LC Display with backlit & 7 key operating panel allows alphanumeric entries to enter information about product (product name, number, batch number) & user (name of the user and comments). |
|
Menu driven operation makes user friendly |
|
Selectable types of operation with Friability test, Abrasion (Attrition) test with single or double drums |
|
10º tilt facility. |
|
Easy to validate |
|
Calculation of percentage weight loss and displays the results of selected test type |
|
Power failure prompt to discard or continue the test |
|
Parallel Printer Port for taking hard copy of the test report as per GMP |
|
|
|
| |
| Technical Specification |
| |
| Display |
20X4 LC Display with backlit |
| Operation |
Through front operating panel with alpha numeric entries |
| RPM |
20 to 75 |
| Interfaces |
Parallel Printer Interface |
| Accessories |
Standard |
Parallel Printer Interface cable, Mains cord, Two Friability Drums, Sample collecting tray assembly with two drawers, Operating Manual |
| |
Optional |
Epson LX300 dot Matrix printer
Abrasion Drum |
| Dimensions |
250 mm x 250 mm x 250 mm Approx |
| |
IQ/OQ Documents available |
|
| |
| Due to constant research and development, design and specifications may change without prior notice. |
| |
|
|
| |
|
|
